Rinnai RU160EP 15000 to 160000 BTU/Hr Tankless Water Heater

Product Description

The RINNAI RU160EP is a tankless water heater designed for residential, outdoor use. It features a gas input supply rating of 15000 to 160000 BTU/Hour and an electrical input supply rating of 120 Volt AC at 60 Hertz, 12 Volt DC, 4 Amp, 49 Watt. The unit is lead-free and utilizes direct electronic ignition.

• Easy of Installation and Serviceability
• Compact Design to Save Space
• Wi-Fi Technology for Remote Monitoring and Management

Product Highlights

This tankless water heater provides on-demand hot water, saving energy and space. It is suitable for outdoor locations and offers features like automatic frost protection and boiling protection.

Product Information

Standard Information

• Brand: RINNAI
• Manufacturer Part Number: RU160EP
• Country of Origin: Japan

Technical Specifications

• Applicable Standard: ANSI Z21.10.3, CSA 4.3, AHRI
• Electrical Input Supply Rating: 120 Volt AC at 60 Hertz, 12 Volt DC, 4 Amp, 49 Watt
• Gas Input Supply Rating: 15000 to 160000 BTU/Hour
• Gas Type: Liquid Propane
• Ignition Type: Direct Electronic
• Inclusions/Features: Automatic Frost Protection, Boiling Protection, Combustion Fan RPM Check, Flame Failure-Flame Rod, Over Current Glass Fuse, Remaining Flame, 22 AWG Non-Polarized 2-Core Cable, Integrated Controller, Water Flow Sensor, Electronic Water Control Device
• Inlet/Outlet Connection: 3/4 Inch Threaded x 3/4 Inch Threaded
• Options: Condensate Neutralizer, ScaleCutter, Drain Down Kit, Additional Controller, Recess Box, Pipe Cover, Recirculation Pump, DPS/MIS Switch, EZConnect Cable, Control-R Wi-Fi Module, Wireless Accessory
• Relief Valve Details: Isolation and Pressure Relief Valve Supplied
• Temperature Rating: 98 to 140 Deg F
• Type: Residential, Outdoor
• Energy Factor: 0.95
• Pressure Rating: 50 to 150 PSI
• Flow Rating: 8 GPM
• Sound Level: 52 Decibel
• Brand: Rinnai
• Series: SE+
• Maximum BTU: 160 MBH
• Location: Outdoor
• Fuel Type: Propane Gas
• Compliance: Complies with South Coast Air Quality Management District 14 ng/J or 20 ppm NOx emission levels
• Voltage: 120 VAC
• Frequency: 60 Hz
• DC Voltage: 12 VDC
• Amperage: 4 A
• Wattage: 49 W
• GPM: 8
• Lead-Free: Yes
• Application: Residential
• BTU (Max): 160000
• BTU (Min): 15000
• Product Type: Tankless Heater
• Energy Star Rated: Yes
• Installation Type: Outdoor Only
• Temperature Range (F): 98°F to 140°F
• Flow Rate at 40F Temp Rise (GPM): 7.7
• Flow Rate at 50F Temp Rise (GPM): 6.2
• Flow Rate at 60F Temp Rise (GPM): 5.2
• Flow Rate at 70F Temp Rise (GPM): 4.4
• MPN: RU160EP
• Recirculation Capable: Yes
• Residential Energy Star: Yes
• Uniform Energy Factor: 0.93
• Domestic Hot Water Flow Rate (Maximum): 9 GPM / (34.1 l/min)
• Wi-Fi Capable: Yes
• SCAQMD Approved: Ultra Low NOx
• Warranty – Residential Heat Exchanger (months): 180
• Warranty – Residential Labor (months): 12
• Warranty – Residential Parts (months): 60
• Part Number: RUR160EP
• Item Package Quantity: 1
• Installation Method: Wall Mounted
